Description
- Features:
- Extreme Power in a Mini Compact Footprint
- Conformal Coated PC Board to Resist Moisture, Dust and Extreme Heat
- 1 Ohm Stable Design
- 4 Layers PCB design with SMD parts
- Built-in Noise Reduction Circuitry
- Full MOSFET with High Grade Switching Devices
- Built-in Auto Sensing Turn On Function (Hi-Inputs)
- 12V Remote Output for External Devices (Hi-Inputs)
- -3 ~ + 12DB Variable Bass Boost 40 Hz - 100 Hz
- Advanced 5 Way Protection Circuitry
- RCLX ~ Railcap Booster (Optional)
- World Wide Standards Compliant (RoHS, E-Mark, CTA-2006, CE)
- Specifications:
- Peak Output Power @ 14.4V: 2800W Max Mono
- 1 Ohm RMS: 1400W X 1
- 2 Ohm RMS: 700W x 1
- 4 Ohm RMS: 450W x 1
- 4 Ohm Bridged: N/A
- Input Level: 0.2~9.0v
- Freq. Response: 10Hz~150KHz
- THD at 4 Ohm Load 30% Rated Power: <0.03%
- S/N Ratio: >85dB
- BassBoost: 40Hz~100Hz
- Minimum Load: 1 Ohm Mono
- Gain Remote: UR1 (Optional)
- Dimension: 1.6"H x 4.25"W x 11.50"L
