FEATURES
- 1" Throat Size
- Trim Bezel Diameter 57mm / 2.25 Inches
- Field Replaceable Voice Coil
- Die Cast Aluminum Frames
- High Temperature 4 Ohm Voice Coils
- High Density Neodymium Magnets
- 140 Watts Peak Power
- CNC Aluminum Phase Plug To Reduce Heat
SPECIFICATIONS
- Throat Size : 1", 25.4mm
- Nominal Impedance : 4 Ohm
- Power Rating RMS : 70 Watts Per Pair / 35 Watts Each
- Max Power : 140 Watts Per Pair / 70 Watts Each
- Usable Frequency Range : 3KHz - 25KHz
- Sensitivity : 102 dB 2.83v @ 1m
- Magnet Weight : 0.63oz, N45
- Filter : N/A
- Voice Coil Diameter : 1"
- DC Resistance (Re) : 3.6 Ohm
- Overall Diameter : 2.2", 57mm
- Mounting Holes Diameter : 1.38", 35mm
- Depth : 2.16" / 55mm
- Diaphragm Material : Titanium
- Magnet Composition : Neodynium
