Designed for professional-grade sound, the PRV Audio 12MR1000 PRO delivers rich, accurate midrange in compact sealed, horn-loaded, or vented enclosures. Equipped with a large 3″ CCAW voice coil and vented cooling, it handles extended high-output use with clarity and durability—perfect for high-SPL car systems, live audio, and home theater setups.
Key Features
- 12″ midrange driver (8 Ω) with 1000 W RMS (Program) power handling
- Premium paper cone with cloth surround for smooth midrange response
- 3″ inside/outside-wound CCAW voice coil on a fiberglass former for robust power handling
- Under-spider and rear venting for cooler operation during extended use
- High sensitivity: 99 dB @ 2.83 V / 1 m for efficient, punchy sound
- Nominal Diameter: 12″ (305 mm)
- Impedance: 8 Ω
- Power Handling (RMS): 1000 W Program / 500 W Nominal
- Max Peak Power: 2000 W
- Sensitivity: 99 dB @ 2.83 V / 1 m
- Frequency Response (–10 dB): 70 Hz – 6,500 Hz
- Recommended HP Crossover: 125 Hz @ 12 dB/oct
- Voice Coil: 3″ CCAW on fiberglass, 11 mm winding depth
- Cone Material: Paper/glass fiber; Frame: Cast aluminum
- Dimensions: OD ~12.40″; Cutout ~11.16″; Depth ~5.12″; Overall Depth ~5.61″
- Weight: ~16.3 lb
