Description
- E-Series
- Speaker Design: 12″ SVC
- Woofer [in, mm] : 12in 305mm
- Rated Impedance: 4 ohm
- Continuous Power Handling [Watts] : 500W Per Pair / 250W Each
- Peak Power Handling [Watts] : 1000W Per Pair / 500W Each
- Frequency Response [Hz] : 25~500Hz
- Mounting Hole Diameter [in, mm] : 11.18in / 284mm
- Top Mount Depth [in, mm] : 0.79in / 20mm
- Bottom Mount Depth [in, mm] : 5.43in / 138mm
- Hole Cut-Out Diameter: 11.18in / 284mm
- Woofer Material: Injection PP
- Surround Material: Rubber
- Magnet Material: Ferrite
- Trim Ring: Yes
- Zn [Ω] : 4.82 ohm
- fs [Hz] : 29Hz
- SPLo [dB@1W,1M] : 86.4dB
- Qts: 0,49
- Qms: 5,58
- Qes: 0,54
- Re [Ω] : 3,6
- Vas [Liters): 83,8
- Xmax ] [mm] : 10
