Audiopipe APHF-1500D-H1 High Frequency Mono Block Amplifier – 1500W RMS, Full-Range Class D
The Audiopipe APHF-1500D-H1 is a competition-grade, full-range mono block amplifier engineered for high-intensity pro audio and Brazilian-style sound systems. Utilizing advanced Full Bridge Class D technology, this compact powerhouse delivers a true 1500 Watts RMS at 1-ohm with exceptional efficiency. Unlike traditional mono amplifiers, the APHF-1500D-H1 features a massive 10Hz to 20kHz frequency response, allowing it to drive everything from deep sub-bass to crystal-clear high-frequency driver arrays. With an integrated clipping indicator, high-grade MOSFET power supply, and a small-footprint heatsink, this amplifier is built for elite-level audio builds where space is limited but power demands are extreme.
Key Features
The Audiopipe APHF-1500D-H1 is a competition-grade, full-range mono block amplifier engineered for high-intensity pro audio and Brazilian-style sound systems. Utilizing advanced Full Bridge Class D technology, this compact powerhouse delivers a true 1500 Watts RMS at 1-ohm with exceptional efficiency. Unlike traditional mono amplifiers, the APHF-1500D-H1 features a massive 10Hz to 20kHz frequency response, allowing it to drive everything from deep sub-bass to crystal-clear high-frequency driver arrays. With an integrated clipping indicator, high-grade MOSFET power supply, and a small-footprint heatsink, this amplifier is built for elite-level audio builds where space is limited but power demands are extreme.
Key Features
- High Frequency (HF) Full-Range Mono Block: Capable of powering subwoofers, mid-ranges, or high-frequency drivers
-
Power Handling (RMS @ 14.4V):
- 1500W x 1 @ 1Ω
- 1000W x 1 @ 2Ω
- 500W x 1 @ 4Ω
- Full Bridge Class D Topology: Maximizes power-to-size ratio and overall electrical efficiency
-
Precision Audio Tuning:
- Variable High Pass Filter: 10Hz – 80Hz (12dB/Oct)
- Variable Low Pass Filter: 80Hz – 20kHz (12dB/Oct)
- Adjustable Bass Boost: 0–12dB (Variable 35Hz – 90Hz)
- System Monitoring: Integrated LED indicators for Power, Protection, and Clipping (Distortion)
- Remote Level Control: Includes a remote bass knob for real-time output adjustment from the dash
- Robust Construction: Features 0-gauge power/ground terminals and 4-gauge speaker terminals
- Advanced 4-Point Protection: Thermal, short circuit, over-voltage (16V), and under-voltage (9V) circuitry
- Frequency Response: 10Hz – 20kHz
- Signal-to-Noise Ratio: >85dB
- Dimensions: 5.9" L x 9.0" W x 2.9" H
