Description
Diamond Audio NEO15006DSP 1500W RMS Class D 6-Channel Amplifier with Integrated DSP
Upgrade your vehicle's audio system with the Diamond Audio NEO15006DSP, the definitive solution for audiophiles seeking the perfect balance of multi-channel flexibility and sophisticated tuning. Engineered as a high-efficiency Class D 6-channel amplifier, this powerhouse delivers a massive 1500 Watts RMS total output, providing the dependable strength needed to drive complete active systems or high-output multi-speaker setups with absolute authority. What truly sets this amplifier apart is its built-in, full-service 8-channel Digital Signal Processor (DSP), which gives you total, professional-grade command over your entire soundstage with 31 bands of parametric EQ per channel, precise crossovers, time delay, and channel linking.
Built to perform flawlessly in diverse and challenging environments, the NEO15006DSP features a highly compact, marine-ready, and water-resistant chassis, making it the ideal choice for high-end car audio, motorcycles, marine, and powersports installations alike. It boasts exceptional modern vehicle compatibility with EV-friendly voltage stability (8V-17V), high-voltage signal inputs up to 20V, and selectable on-board load resistors for seamless integration with complex factory (OEM) electrical systems. Complete with staggered RCA connections for clean wiring, high-current quick-connect power blocks, and 2-channel RCA preamp outputs for system expansion, this amplifier delivers cutting-edge sonic clarity in a rugged, space-saving footprint.
Key Features & Specifications
Upgrade your vehicle's audio system with the Diamond Audio NEO15006DSP, the definitive solution for audiophiles seeking the perfect balance of multi-channel flexibility and sophisticated tuning. Engineered as a high-efficiency Class D 6-channel amplifier, this powerhouse delivers a massive 1500 Watts RMS total output, providing the dependable strength needed to drive complete active systems or high-output multi-speaker setups with absolute authority. What truly sets this amplifier apart is its built-in, full-service 8-channel Digital Signal Processor (DSP), which gives you total, professional-grade command over your entire soundstage with 31 bands of parametric EQ per channel, precise crossovers, time delay, and channel linking.
Built to perform flawlessly in diverse and challenging environments, the NEO15006DSP features a highly compact, marine-ready, and water-resistant chassis, making it the ideal choice for high-end car audio, motorcycles, marine, and powersports installations alike. It boasts exceptional modern vehicle compatibility with EV-friendly voltage stability (8V-17V), high-voltage signal inputs up to 20V, and selectable on-board load resistors for seamless integration with complex factory (OEM) electrical systems. Complete with staggered RCA connections for clean wiring, high-current quick-connect power blocks, and 2-channel RCA preamp outputs for system expansion, this amplifier delivers cutting-edge sonic clarity in a rugged, space-saving footprint.
Key Features & Specifications
- Amplifier Type: High-efficiency Class D 6-Channel Full Range Amplifier with an integrated 8-channel Digital Signal Processor (6CH internal, 2CH output).
- 4-Ohm RMS Power: 150 Watts x 6 Channels @ 4 Ohms.
- 2-Ohm RMS Power: 250 Watts x 6 Channels @ 2 Ohms.
- Bridged RMS Power: 500 Watts x 3 Channels @ 4 Ohms Bridged.
- Advanced DSP Tuning: Features a 31-band parametric EQ per channel, precise crossovers, time alignment, and channel linking via PC or Android smart device programming.
- Seamless OEM Integration: Equipped with high-voltage signal inputs (0.4V - 20V) and selectable onboard load resistors (10Ω, 20Ω, 60Ω, 20kΩ) to bypass factory system protection circuits.
- EV & Hybrid Friendly: Advanced power supply operates safely within a wide 8V to 17V range without compromising your electric or hybrid vehicle's electrical integrity.
- Marine-Ready Construction: Water-resistant, compact chassis designed to withstand moisture and vibration in cars, motorcycles, marine vessels, and off-road vehicles.
- System Expansion: Features 2 RCA preamp outputs and compatibility with the NeoDRC1 Diamond Remote Commander (sold separately) for ultimate control.
- Dimensions: Ultra-compact footprint measuring 11.32" (L) x 4.07" (W) x 1.38" (H).
