Description
- RMS WATTS @ 4 Ohms @ 0.5% THD+N: 4 x 90W + 1 x 380W
- RMS WATTS @ 2 Ohms @ 0.5% THD+N: 4 x 125W + 1 x 650W
- RMS WATTS @ 1 Ohms @ 0.5% THD+N: 4 x ***W + 1 x 1000W
- RMS WATTS @ 4 Ohms @ 0.5% THD+N: 2 x 250W + 1 x 380W
- Frequency Response: 20Hz - 350kHz
- Linear Bandwidth 20Hz to 65kHz +/- 3 dB
- High Pass Crossover Continuously variable Channel 1-4: (50-5kHz)
- Low Pass Crossover Continuously variable Channel 1-4: (50-400Hz)
- Low Pass Crossover Continuously variable Channel 5: (50-250Hz)
- Supply Voltage: 9 - 16V
- Amplifier Efficiency: >60%
- Damping Factor: 200dB
- Signal to Noise Ratio: >90dB
- T.H.D. & Noise: 0.5%
- Bass Boost: 0-18dB Variable
- Variable Input Level Control: 0.2V - 6.0V
- Fuses: ***A recommended (TBD)
- Dimensions (L x W x H): 17.32" x 9.25" x 2.75" (440x235x70mm)
