Description
- Nominal Impedance: Dual 4-ohm
- BL: 13.91
- Inputs: Dual Coil
- Subwoofer Frequency Range: 30 Hz - 400 Hz
- Voice Coil Size: 2.5 in
- Material: Woven Glass Fiber and Kraft Paper
- Magnet Size: 132 oz
- Sensitivity (1W / 1M): 87.08 dB
- Motor Structure: 132 oz
- Cutout Diameter: 11.0"
- Mounting Depth: 5.4 in
- Xmax: 11.5
- Spl: 87.08
- No: 0.308%
- Qts: 0.334
- Qes: 0.352
- Qms: 6.548
- Mms: 238.46 g
- Cms: 129 uM/N
- Vas: 47.50 Ltr
- SD: 510.71
- Fs: 28.7 Hz
- Test Impedance: 1.58-ohm
- VC Impedance: 4-ohm + 4-ohm
- Size: 12 in
- Sensitivity: 87.08 dB
- Frequency Response: 30 Hz -400 Hz
- Voice Coil Size: 2.5 in
- Power Handling (RMS/Peak): 450 / 900 watts
- New PBX logo dust cap
- Woven Glass Fiber Cone With Pressed Kraft Paper Reinforcement
- Nitrile Butadiene Rubber (NBR) Surround
- 2.5" Vented BKSV Voice Coil Former
- Perimeter Aero-Vent Voice Coil Cooling Vents
- Non Resonance DDC Coated Cast Aluminum Basket
- XTRA XTRA Large Double Stacked Motor Structures
- Square Spring Loaded Nickel Plated Input Terminals
- Optimally Designed for Small Sealed Enclosures
- Compact Design
