Description
- Selectable Subwoofer EQ: 0-18 dB Gain @ 45Hz
- Variable Subsonic Freq: N/A
- Inputs: 3 Pairs of RCA
- Equalization Boost/Cut: 0 - 18 dB
- Subwoofer Frequency Range: 20 Hz - 250 Hz
- Power Supply: Unregulated PWM
- Height: 2.3"
- Width: 8.3"
- Depth: 16.8"
- 4-ohm Mono Power: 200 watts x 2 + 400 x 1 (2-ohm)
- 4-ohm Power: 50 watts x 4 + 200 x 1
- 1-ohm Mono Power: N/A
- 2-ohm Power: 100 watts x 4 + 400 x 1
- Subwoofer EQ Frequency: 45 Hz
- Variable Subwoofer EQ: 0 - 18 dB
- Low-Pass Crossover Freq: 40 Hz - 250 Hz
- High-Pass Crossover Freq: 40 Hz - 250 Hz
- Peak Power: 1600 watts
- Crossover Slope: 12 dB
- Dimensions (in Inches): 16.8" x 8.3" x 2.3"
- Input Sensitivity: 0.25 V - 6.0 V
- S/N Ratio: >94 dB
- Total Harmonic Distortion: 0.05% at Rated Power
- Strapped Output Power @ 2ohms: N/A
- Output Power (14.4 V) @ 4 ohm: 50 watts x 4 + 200 x 1
- Output Power (14.4 V) @ 2 ohm: 100 watts x 4 + 400 x 1
- Output Power (14.4 V) @ 1 ohm: N/A
- Channels (mono): 5
- Frequency Response: 20 Hz - 22 kHz
- 5-Channel 800 Watt High Efficiency Class A/B Design
- 2-ohm Stable (4-ohm in Bridged Mode)
- PWM MOSFET Power Supply
- Low Level RCA Input/Low Level RCA Pass Through Output
- Remote Soft Delay Turn On/Off Circuit
- Variable High/Low Pass Electronic Crossover
- Variable 18dB Bass Boost EQ @ 45 Hz
- Variable Gain Control
- Protection Circuit: Impedance Over-load, Speaker Short, Circuit, Thermal Overheating, and DC Output.
- Wired Secondary Remote Gain Control (Optional PB-GAIN1)
- Switchable Logo Back Lighting
